The SmartArray Q4 Tunable White LED Module is a high-performance lighting solution that packs a lot of power into a small, square-shaped design. This module is equipped with four Nichia E17A series LEDs that deliver brilliant light with a CRI value of over 80. With Tunable White technology, the module can produce a range of colour temperatures from warm white (2000K) to near daylight (6500K), making it perfect for use in dimmable luminaires.
The SmartArray Q4 TW is a great choice for use in high-intensity luminaires, such as those found in offices, hospitals, and schools. It provides smooth adjustment of the colour temperature from warm white to cold white, while maintaining a constant colour temperature over the entire dimming range. Thanks to its compact and flat design, this module is easy to install in almost any luminaire design, making it a versatile and convenient lighting solution.
The SmartArray LED modules are developed and produced in Germany, and are equipped with the high-quality Nichia LEDs that are known for their outstanding performance and natural light output. These modules are also available with Dim2Warm and Tunable-White technology, which generate a particularly pleasant light spectrum, making them ideal for use in living and working areas.
In terms of performance, the SmartArray Q4 Tunable White LED Module offers an impressive efficiency of up to 134 lm/W and a typical luminous flux of 170 lm at 2000K and 270lm at 6500K. It operates at a constant current of 350mA and a power of 2W. The module's very small dimensions of 13.5 x 13 x 1.4 mm make it easy to install, while the Nichia binning technology ensures uniform white light with a 3-step MacAdam binning.
This module comes with a 5-year warranty, and is made in Germany to ensure high quality and reliability. It is an excellent replacement for Chip-on-Board modules, and is ideal for luminaire manufacturers and industrial applications.
|Weight brut (g)||1.000000|
|Color Rendering Index||80|
|Luminous Flux Typ (lm)||270|
|Efficacy (lm per W)||135|
|Energy Class 2022||D|
|Lifetime for residential, 3h daily (yrs)||55|
|Product lifetime (h)||60000|
|Lifetime for commercial, 12h daily (yrs)||14|
|Forward Current Max||700mA|
|Manufacturer Product Code||30774|
|Product Family||Smart Array LED strip|
|LEDs number per sales unit||4|
|Dimensions: Length (cm)||1.35|
|Dimensions: Width (mm)||13|
|Dimensions: Height (mm)||1.4|
|Forward Voltage Typ (V)||6|
