Constant Voltage Power Supply Mean Well HLG-150H-24B IP67 230V to 24V 6.3A 150W DIM
€71.75
Stock Germany >10 pcs
SKU
95189
- Buy 5 for €53.64 each and save 25%
Constant Voltage Power Supply Mean Well HLG-150H-24B IP67 230V to 24V 6.3A 150W DIM
Mean Well constant voltage LED transformer for use with LED modules and strips that require 24VDC voltage. The components can be connected in parallel so the total power of the chain is max 6300mA or 150 W. Compact size, dimensions(mm): 228*68*38.8mm.Features:
- 90~305VAC input, built-in active PFC function
- 96% high efficiency (HLG-600H)
- Metal case, IP67 design for indoor or outdoor installations
- Function options: 3 in 1 dimming (1~10Vdc or 10V PWM signal or resistance)
- Type "HL" LED drivers for use in Class I, Division 2 hazardous (Classified) location luminaries
- Suitable for LED street lighting, outdoor LED lighting and general outdoor applications with high IP requirement
- 7 years warranty
| SKU | 95189 |
|---|---|
| Weight brut (g) | 1150.000000 |
| Brand | Mean Well |
| Manufacturer Part Number | 4021087010481 |
| Manufacturer Product Code | HLG-150H-24B |
| Output Current (Range) | max 6300mA |
| Transformer Output Voltage | 24V |
| Power (W) | 150 |
| IP Protection | IP67 |
| Dimmable | Dimmable |
| Dimensions | 228x68x38.8mm |
| Dimensions: Length (cm) | 22.8 |
| Dimensions: Width (mm) | 68 |
| Dimensions: Height (mm) | 38.8 |
| Product Family | HLG |
| Availability beyond shown stock: | YES |
