UVC Bolb 3S4P-S6060 LED Module 12 LEDs 275nm 1200mW 24W 30cm
- Highly efficient UV-C LED module from Bolb with twelve high-power UV-C LEDs from the 6060 series
- Achieves an optical output of an incredible 1200 mW with the industry's highest efficiency in energy conversion in the UV-C sector
- The UV-C LEDs operate at a wavelength of 275 nm and can inactivate viruses, bacteria and other germs with an accuracy of up to 99.99999%
- The Bolb 3S4P-S6060 UV-C LED module has an excellent price-performance ratio and is suitable for applications in the industrial sector, especially for disinfection or sterilization
- Bolb Inc. is a U.S.-based manufacturer of high-power solid-state UVB/C lamps and ranks as a leading developer of the industry's most efficient UVC LEDs
- Linear LED module with dimensions of 300 x 30 x 4 mm, and LED dimensions of 6 x 6 x 1.35 mm
- Suitable for disinfection (e.g. water) and sterilization (e.g. surfaces, air) applications.
The Bolb elongated UV-C LED module is a powerful disinfection and sterilization solution for industrial applications. The module is equipped with twelve S6060 High-Power UV-C LEDs from the US company Bolb that operate at a wavelength of 275 nm and achieve an optical output of 1200 mW. The Bolb UV-C LEDs have the highest efficiency in energy conversion in the UV-C sector, making them the most efficient in the industry. They are able to inactivate viruses, bacteria and other germs with an accuracy of up to 99.99999%.
The Bolb 3S4P-S6060 UV-C LED module has excellent price-performance ratio and is exclusively suitable for applications in the industrial sector. Please note that the UV-C LEDs are non-visible light and can pose a risk to the eye and skin even when exposed for a short time. Therefore, it is important to seek advice from the staff before purchasing this product.
Bolb Inc. is a leading provider of deep UV LED solutions based in the US. The company is a manufacturer of high-power solid-state UVB/C lamps and a leading developer of the industry's most efficient UVC LEDs. Bolb's technical expertise ranges from epitaxy to the manufacture of equipment and complete UV systems. Its ultra-efficient LEDs are being integrated into a new generation of portable and home appliances, medical devices and industrial processing equipment, contributing to a healthier world.
The Bolb 3S4P-S6060 UV-C LED module is a linear LED module with twelve high-power Bolb UV-C LEDs from the 6060 series. It has a radiant UVC power of 1200 mW and typical input power of 24W at 24V and 1000mA. The module has extremely high efficiency and an inactivation rate of up to 99.99999%. The LED dimensions are 6 x 6 x 1.35 mm and the dimensions of the module are 300 x 30 x 4 mm. The Bolb 3S4P-S6060 UV-C LED module is suitable for disinfection of water and sterilization of surfaces and air, making it an ideal choice for a variety of industrial applications.
Features of the Bolb 3S4P-S6060 UV-C LED module
- Linear LED module with twelve high-power Bolb UV-C LEDs
- 6060 series
- Wavelength: 275 nm
- Radiant UVC power: 1200 mW
- 24V at 1000mA, total input power 24W
- Extremely high efficiency
- Inactivation rate of up to 99.99999%
- Excellent price-performance ratio
- Risk group 3 (EN 62471)
- LED dimensions (L x W x H): 6 x 6 x 1.35 mm
- Dimensions of the module: 300 x 30 x 4 mm
Application areas
- Disinfection (e.g. water)
- Sterilization (e.g. surfaces, air)
Warnings
- The article is a powerful UV-C LED which can be used for the disinfection of surfaces. It emits at a wavelength of 275 nm which is not visible to the human eye.
- It is imperative to ensure that users wear suitable protective clothing against UV radiation at all times. All skin and eye contact must be avoided.
- We recommend the use of the following protective agents:
- Safety goggles
- Gloves
- Face Shield
- Protective clothing that shields UV light from the skin
- Wear protective clothing at all times during use and ensure that no other persons are within reach of the radiation source without taking appropriate safety precautions.
- Light can reflect, therefore special precautions have to be taken with reflecting surfaces (e.g. mirrors).
- If skin tissue is exposed to the light source, skin irritation comparable to sunburn may occur. If necessary, treat the affected areas with a suitable cream or consult a physician.
- Low wavelength UV light can cause permanent damage to the retina in severe cases. Make sure to wear protective goggles at all times when using the device.
| SKU | 38264 |
|---|---|
| Weight brut (g) | 1.000000 |
| Color | UVC Ultraviolet |
| Viewing Angle | 150° |
| Warranty (months) | 24 |
| Wavelength (nm) | 275 |
| Manufacturer Product Code | 3044235 UV-C |
| LEDs number per sales unit | 12 |
| Dimensions: Length (cm) | 30 |
| Dimensions: Width (mm) | 30 |
| Dimensions: Height (mm) | 4 |
| Brand | Bolb |
| Manufacturer Part Number | 4062986002528 |
