NICHIA NV4W144AR 5050 Package Cold White High Power SMT LED 1050lm 5000K
€13.89
Ships in 3-6 weeks
SKU
N-65177.01
- For orders above packing quantity or delivery time inquiries, contact us
- Orders below the LED packing quantity are considered samples for a future project
- To supply samples, Nichia requires project details, that we will request after you order
- An accurate delivery time will be provided after we receive your order, including project details for sample orders
- LEDs from an official Nichia distributor.
Compact 5x5mm high power LED from Nichia, designed for street or flood lighting.
Features
- 5050 Package
- 8-19W Power LED
- Single Chip
- Ceramic casing
- Dimensions (LxWxH): 5.0x5.0x2.3mm
- With 5 SDCM (standard deviation of color matching) as standard, 3 or 7 SDCM optional
- Individual and flexible use
Color temperature options
- 5 SDCM offered as standard
- Center bin at extra cost
Application areas
- Street lighting
- Lamp and spot lighting
- High bay and Downlights
Delivery and price rules:
- Price for 1 pcs valid up to one full reel
- Price for one reel valid up to 5 reels
- For more than 5 reels inquire for price
- Usual delivery time is 5-6 weeks, depeding on color temperature and CRI requirements
| SKU | N-65177.01 |
|---|---|
| Weight brut (g) | 1.000000 |
| LED Size | 5x5 mm |
| LED Family | Nichia 144A Series |
| LED Installation Package | Emitter |
| Color Rendering Index | 90 |
| Color | Cold White |
| Color Temperature | 5000K |
| Viewing Angle | 120° |
| Luminous Flux Typ (lm) | 1050 |
| Forward Current Typ | 700ma |
| Forward Voltage Typ (V) | 11.9 |
| LED Power (W) | 8.33 |
| Manufacturer Product Code | NV4W144AR |
| Brand | Nichia |
