iFlex-RGBW-1080 LED Strip RGB-White CRI80 3000K 1180lm 5V 60 individually controllable LEDs/m 5m reel
- 300 RGBW LEDs per 5 m reel (60 LEDs per meter), each individually controllable
- Red, green, blue and warm white 3000K (CRI80) in every LED
- Up to 140 lm red, 430 lm green, 90 lm blue and 440 lm white per reel
- 5 V DC operation, dimmable
- 5 W per color, 20 W with all colors on
- Can be cut after each LED (every 16.67 mm)
- Lifetime of more than 40,000 hours (L80B10)
- Made in Germany, 5-year warranty
iFlex-RGBW-1080 Addressable LED Strip RGB + Warm White, 5 V
The iFlex-RGBW-1080 is a flexible LED strip with 300 individually controllable RGBW LEDs on 5 m (60 per meter). Every LED combines red, green, blue and a warm white 3000K chip, and each one can be addressed on its own, so colors, white light and moving effects can run along the strip, LED by LED. This makes it ideal for dynamic lighting in living spaces, bars, shop windows, exhibition stands and creative projects.
The strip requires a compatible digital (pixel) controller. For a ready-to-use solution, choose our iFlex-RGBW-1080 LED Strip Set (SKU 40664), which includes controller, IR remote control, power supply and clip connector.
The iFlex is made in Germany with our reel-to-reel process. It can be cut after each LED (every 16.67 mm) to the exact length required, and is installed quickly with its self-adhesive back, without any additional cooling.
Features of the iFlex-RGBW-1080 LED Strip
- 300 RGBW LEDs per 5 m reel (60 LEDs per meter), each individually controllable
- Red, green, blue and warm white 3000K (CRI80) in every LED
- Up to 140 lm red, 430 lm green, 90 lm blue and 440 lm white per reel
- 5 V DC operation, dimmable
- 5 W per color, 20 W with all colors on
- Can be cut after each LED (every 16.67 mm)
- Self-adhesive back, no cooling required
- Lifetime of more than 40,000 hours (L80B10)
- Dimensions: 5000 x 10 x 1.72 mm
- 5-year warranty
- Made in Germany
Applications of the iFlex-RGBW-1080 LED Strip
The iFlex-RGBW-1080 LED Strip is designed for the following main applications:
- Cove lighting: In ceiling or wall coves, the strip provides warm white ambient light for everyday use, and colors or running effects for special moments. Learn how to plan it in our cove lighting guide.
- Multi-color lighting with 4 channels: Thanks to the separate white chip, colors and white can be mixed freely, and because each LED is addressable, effects such as color runs, gradients and chasers are possible, ideal for bars, event spaces, shop windows, furniture and exhibition stands. Discover our 4-channel LED strips and modules (RGB-W, multi-color).
- White light: The dedicated warm white chip provides real, pleasant white light with CRI80 instead of a mixed RGB white. The 3000K color temperature gives a soothing warm white light for a relaxing atmosphere. Find out which color temperature suits your project in our guide Choosing the right color temperature for LED lighting.
Technical Data of the iFlex-RGBW-1080 LED Strip
- Article number (SKU): 40595
- Equivalent model: iFlex300 ECO
- Light colors: Red, green, blue and warm white 3000K
- Dominant wavelength: Red 615-625 nm, green 525-535 nm, blue 465-470 nm
- Color rendering index (white): CRI80, photometric code 830/339
- Luminous flux (max.): Red 140 lm, green 430 lm, blue 90 lm, white 440 lm per reel (28 / 86 / 18 / 88 lm per meter)
- Beam angle: 120°
- Lifetime: >40,000 h (L80B10C1)
- Operating voltage: 5 V DC, dimmable
- Power: 5 W per color, 20 W with all colors on (5 m reel)
- Number of LEDs: 300 per reel, 60 per meter, individually controllable
- Dimensions: 5000 x 10 x 1.72 mm (L x W x H)
- Cutting interval: after each LED (16.67 mm)
- Operating temperature at Tc: -40°C to +85°C
- Ambient temperature: -40°C to +50°C
- Storage temperature: -40°C to +100°C
- Certifications: CE, RoHS, REACH
- Photobiological safety (EN 62471): Risk group RG0
Installation and Operation
- Cutting: the strip can be cut with scissors after each LED, at the marked cutting points.
- Mounting: clean and degrease the surface, then fix the strip with its self-adhesive tape. For the best heat transfer, light diffusion and mechanical protection, we recommend mounting it in one of our aluminum profiles.
- Connection: solder the supply and data leads to the marked pads at the input end of the strip and connect them to a compatible digital (pixel) controller; observe the signal direction, feeding the data line in at the input end of the strip.
- Power supply: operate the strip with a stabilized 5 V DC constant voltage LED driver that has short-circuit, overload and overtemperature protection. A full 5 m reel draws 20 W.
- Long runs: at 5 V, voltage drop increases with length; for full 5 m runs, use adequately sized cables and feed power at both ends if needed to keep brightness and colors uniform.
- Handling: avoid sharp bending and mechanical stress on the components, observe standard ESD precautions, and keep the strip away from aggressive chemicals. Store and operate it at 10% to 60% relative humidity.
- Safety: installation must comply with all applicable electrical and safety standards and should be carried out by a qualified electrician.
Who We Are: Ledrise, Professional LED Strips Made in Germany
Ledrise is the international online shop for high-performance LED strips and modules that we develop and manufacture in our own production facility in Germany and ship directly from there. With more than 20 years of experience in LED technology, our team of more than 70 people in Germany, Hong Kong and Romania has gained extensive application knowledge across many sectors, and thousands of business customers and consumers on five continents rely on us as their LED technology partner.
We use only LEDs from market leaders such as Nichia, Seoul Semiconductor, Cree, Samsung and ams OSRAM. Beyond standard products, we design and prototype custom LED modules, select and integrate optics, housings and drivers, and test and validate every solution in our in-house measuring and testing laboratory, supporting you from the first lighting concept to serial production.
Our Quality Promise
- Certified quality: our quality management is certified to DIN EN ISO 9001 and covers every step, from product development to customer service. Our manufacturing center in Germany is also certified to ISO 14001 for environmental management and ISO 45001 for occupational health and safety.
- Reel-to-reel manufacturing, unique in Europe: our fully automated reel-to-reel flex line uses plasma direct metallization to produce robust, flexible circuit boards in continuous lengths of up to 100 meters, with fewer interconnections and less material waste.
- Precision at every step: automated solder paste printing with inline inspection, high-speed ASM SIPLACE component placement, controlled reflow soldering, and automatic optical inspection that detects missing, offset or misaligned components.
- Full traceability: production batches are marked and tracked with laser-engraved barcodes.
- Honest data: the performance values in our datasheets match those in real-world applications.
- Long-term security: a 5-year warranty on this LED strip (see our warranty terms) and professional support for your lighting projects.
Learn more about Ledrise and our reel-to-reel flexible LED strip manufacturing in Germany.
| SKU | 40595 |
|---|---|
| Weight brut (g) | 80.000000 |
| Color | RGBW |
| Color Temperature | 3000K |
| Color Rendering Index | 80 |
| Luminous Flux per meter | 88 |
| Luminous Flux Typ (lm) | 1100 |
| Power (W) | 5 |
| Dimmable | Tunable White, Dimmable, Adjustable color |
| Viewing Angle | 120° |
| Warranty (months) | 60 |
| Product lifetime (h) | 40000 |
| Forward Current Max | 1000mA |
| Product Family | LumiFlex1080 |
| Strip Type | Flexible |
| LEDs per meter | 60 |
| LEDs number per sales unit | 300 |
| Dimensions | 5000x10x1.72 |
| Dimensions: Length (cm) | 500 |
| Dimensions: Width (mm) | 10 |
| Dimensions: Height (mm) | 1.72 |
| Can be cut at (mm) | 16.67 |
| Brand | Lumistrips |
| Manufacturer Part Number | 40595 |
| Forward Voltage Typ (V) | 5 |
