Nichia SMD LED UV NVSU119C 405nm 1420mW at 700mA 2.2W Emitter
€8.36
Stock Germany >500 pcs
SKU
14358.03
- Nichia is one of the world's largest and most innovative LED manufacturers, known for durability, brightness, and homogeneity
- The NVSU119C has a UVA radiant power of 1420mW at 405nm wavelength, making it highly suitable for industrial and commercial applications
- Nichia's fine selection of products allows for greater added value for professional processing
- The NVSU119C is available with three different wavelengths, providing versatility for various application
- Fixtures with multiple LEDs can be used for disinfection, plant growth, ink or resin curing, and lithography for medical, industrial, and commercial applications
- The NVSU119C has a 120-degree viewing angle and a compact size of 3.5x3.5x2.0mm
- It is important to seek advice from our employees before ordering this product due to the potential danger of UV radiation.
Nichia is a leading global manufacturer of high-quality LED products and has been a pioneer in the industry for many years. Their research department is known for its innovative and efficient approach to lighting solutions, and they are credited with inventing the blue LED, which led to the development of white LEDs. Durability, brightness, and homogeneity are among the major strengths of the Nichia brand, and their fine selection allows for greater added value for professional processing.
The Nichia SMD LEDs in the UV range are highly versatile and can be used in a variety of applications. The NVSU119C is available with three different wavelengths, and at a 405nm wavelength, it reaches a power of 1420mW, making it ideal for industrial and commercial applications. Fixtures with multiple LEDs can be used for disinfection, plant growth, ink or resin curing, and lithography for medical, industrial, and commercial applications.
It is important to note that UV radiation is invisible to the naked eye and can pose a danger to the eyes and skin even with short-term exposure. Before ordering this product, it is crucial to seek advice from our employees to ensure safety.
Features
- SMD LED UVA with 1420mW radiant power at 405nm
- Nichia 3535 Package
- Forward current typ: 1160mA at 3.4V
- Power consumption: 2.4W at 1160mA
- 120 degree viewing angle
- Risk group 3 (EN 62471)
- Dimensions LED (LxWxH): 3.5x3.5x2.0
Application areas
- medical engineering
- test and sorting machines
- hardening
- cameras with UV light
| SKU | 14358.03 |
|---|---|
| Weight brut (g) | 1.000000 |
| LED Size | 3.5x3.5 mm |
| LED Family | Nichia UV (New!) |
| LED Installation Package | Emitter |
| Color | UVA Ultraviolet |
| Viewing Angle | 135° |
| Forward Current Typ | 700ma |
| Forward Voltage Typ (V) | 3.4 |
| LED Power (W) | 2.38 |
| Wavelength (nm) | 405 |
| Manufacturer Product Code | NVSU119CT U405 |
| Brand | Nichia |
| Manufacturer Part Number | NVSU119C |
| Availability beyond shown stock: | YES |
| Dimensions: Length (cm) | 0.35 |
| Dimensions: Width (mm) | 0.20 |
| Dimensions: Height (mm) | 0.35 |
