Nichia NF2W757G-MT 3030 757 Series SMD LED Tunable White 2700-6500K CRI80 32lm

€0.34
Ships in 1-6 weeks
SKU
NF2W757G-MT_Ra80_2700-6500K
  • Buy 5000 for €0.17 each and save 50%

With 24% global market share, Nichia is the largest LED manufacturer in the world and inventor of the blue (and also white) light emitting diode. The innovative Nichia research department is a pioneer when it comes to durability, brightness and efficiency, reaching new records on a regular basis.

Blog Posts

Nichia NF2W757GT-MT 3030 757 Series SMD LED Tunable White 2700-6500K CRI80 32lm

NF2W757G-MT uses the standard 757 package with new patented technology to allow the user to smoothly transition CCT’s from 6,500K to 2,700K. The significant innovation is its ability to accomplish color tuning under a small, single light emitting surface (LES), thus achieving superb color uniformity with high color quality; up to 90 CRI in the popular CCT’s. The 2-in-1 tunable white 757 enables thinner, sleeker optical designs, eliminating the need for bulky mixing chambers.

In addition to remarkable color, NF2W757G-MT allows users to improve operational efficiency. With performance on par with the primary 757’s shipping today, the industry’s #1 mid power LED, CCT can now be selected with ease at the time of assembly, shipment or installation vs. carrying inventory of multiple CCT’s. This can dramatically reduce inventory complexity, lead times and cost. NF2W757G-MT will be available in multiple binning options, including 3-step only, to further simplify the implementation.

Nichia’s 757G series mid-power, 3030 LED package uses a proprietary design and thermoset composite material to deliver efficacy and value beyond current high-power LED capabilities.

Further more, with luminous efficacy reaching 220 lumens/watt, the Nichia 757G series surpasses in performance all other commercially available mid-power LEDs as of 2019.

LM-80 and TM-21 reports from Nichia certify also reliability at over 60,000 hours with minimum color shifts.

The unique design attributes in the 757G series ensure great reliability while delivering high visual comfort with uniform light distribution and tighter color control. The differentiation rests with the proprietary thermoset composite packing materials paired with high-efficiency LED chips and specially blended phosphors.

Features

  • Luminous flux: 32 lm
  • Color temperature: 2700-6500 K
  • CRI: 80
  • LED dimensions: 3x3x0.75 mm
  • Typical current: 120 mA
  • Typical voltage: 2.84 V
  • Maximum voltage: 3.1 mA

Color temperature options

  • 3 SDCM offered as standard
  • Center bin at extra cost

Application areas

  • LED lamps and luminaires
  • LED tubes and downlights
  • LED panels and displays

Delivery and price rules:

  • Available in Emitter form
  • Price for 1 pcs valid up to one full reel
  • Price for one reel valid up to 2 reels
  • For more than 2 reels inquire for price
Technical Data
SKU NF2W757G-MT_Ra80_2700-6500K
LED Size 3x3 mm
LED Family Nichia 757G Series
LED Installation Package Emitter
Color Tunable White
Color Temperature 2700-6500K
Color Rendering Index 80
Viewing Angle 120°
Luminous Flux Typ (lm) 32
Forward Current Typ 65 ma
Forward Voltage Typ (V) 2.84
Power (W) 0.19
Luminous Efficacy (lm per W) 169
Manufacturer Product Code NF2W757G-MT_Ra80
Manufacturer Nichia
Dimensions: Length (cm) 3
Dimensions: Width 3
Dimensions: Height 0.75
