Constant Current LED Driver Mean Well LCM-25DA IP20 350 > 1050 mA 230V to 6 > 54VDC DIM

Constant Current LED Driver Mean Well LCM-25DA IP20 350 > 1050 mA 230V to 6 > 54VDC DIM

Constant Current LED Driver Mean Well LCM-25DA IP20 350 > 1050 mA 230V to 6 > 54VDC DIM
Constant Current LED Driver Mean Well LCM-25DA IP20 350 > 1050 mA 230V to 6 > 54VDC DIM

Constant Current LED Driver Mean Well LCM-25DA IP20 350 > 1050 mA 230V to 6 > 54VDC DIM

€39.38
Stock Germany >10 pcs
SKU
95268
  • Buy 5 for €24.72 each and save 37%

Established in 1982, MEAN WELL is considered a pioneer and a leader in standard switching power supplies all over the world.

MEAN WELL is ranked the 6th in global power supply (DC output) makers according to a report by Micro Technology Consultant released in March 2016. For the product coverage of industrial power supplies and the sales volume of LED drivers, we have the confidence to say that MEAN WELL is ranked the No.1 standard power supply manufacturer in the world.

Blog Posts (3)

Constant Current LED Driver Mean Well LCM-25DA IP20 350 > 2400 mA 230V to 6 > 54VDC

Mean Well constant current LED driver for use with discreet LEDs (High Power, COB and so on) or strips that require 350 > 2400 mA current. The output current can be set in this interval. The components must be connected in series so the voltage of the chain is in the interval 6 > 54 VDC.

Dimensions(mm): 105*68*23mm

Features:
  • 180~295VAC input for 40W/60W, 180~277VAC input for 25W
  • Constant current mode
  • Built-in active PFC function
  • Multiple-stage output current level selectable by DIP switch
  • Built-in DALI interface and push dimming function for DA type
  • Suitable for indoor LED lighting applications
  • 5 years warranty
Technical Data
SKU 95268
Weight brut (g) 240.000000
Driver Voltage Range (V) 6 to 54
Output Current (Range) 350 to 1050 mA
Dimmable Dimmable
Dimensions 123.5x81.5x23
Brand Mean Well
Manufacturer Product Code LCM-25DA
Product Family LCM
Availability beyond shown stock: YES
Dimensions: Length (cm) 13.25
Dimensions: Width (mm) 81.5
Dimensions: Height (mm) 23
