Constant Current LED Driver Mean Well PCD-16-700B IP30 700mA 16 > 24V DIM
€30.96
Ships in 3-6 weeks
SKU
95146
Constant Current LED Driver Mean Well PCD-16-700B IP30 700mA 16 > 24V DIM
Mean Well constant current LED driver for use with discreet LEDs (High Power, COB and so on) or strips that require 700mA current. The components must be connected in series so the voltage of the chain is in the interval 16 > 24 VDC. Compact size, dimensions (mm) 84*57*29.5mm.Features:
- AC phase-cut dimming, work with leading and trailing edge TRIAC dimmers
- Constant current design
- Protections: Short circuit/ Over temperature
- 180~295VAC input
- Fully isolated plastic case
- Built-in active PFC function
- IP30 design
- Class 2 power unit/ Pass LPS
- Isolation class II, no F.G.
- Cooling by free air convection
- 3 years warranty
| SKU | 95146 |
|---|---|
| Weight brut (g) | 190.000000 |
| Output Current | 700mA |
| Driver Voltage Range (V) | 16 to 24 |
| Dimmable | Dimmable |
| Dimensions | 84x57x29.5mm |
| Manufacturer Part Number | 4021087006606 |
| Brand | Mean Well |
| Manufacturer Product Code | PCD-16-700B |
| Product Family | PCD |
| Availability beyond shown stock: | YES |
| Dimensions: Length (cm) | 8.4 |
| Dimensions: Width (mm) | 57 |
| Dimensions: Height (mm) | 29.5 |
