Constant Voltage Power Supply Mean Well HLG-320H-12B IP67 230V to 12V 22A 264W DIM

Constant Voltage Power Supply Mean Well HLG-320H-12B IP67 230V to 12V 22A 264W DIM

Constant Voltage Power Supply Mean Well HLG-320H-12B IP67 230V to 12V 22A 264W DIM
Constant Voltage Power Supply Mean Well HLG-320H-12B IP67 230V to 12V 22A 264W DIM

Constant Voltage Power Supply Mean Well HLG-320H-12B IP67 230V to 12V 22A 264W DIM

€135.30
Low Stock Germany, only 1 pcs.
SKU
95194

Established in 1982, MEAN WELL is considered a pioneer and a leader in standard switching power supplies all over the world.

MEAN WELL is ranked the 6th in global power supply (DC output) makers according to a report by Micro Technology Consultant released in March 2016. For the product coverage of industrial power supplies and the sales volume of LED drivers, we have the confidence to say that MEAN WELL is ranked the No.1 standard power supply manufacturer in the world.

Blog Posts (4)

Constant Voltage Power Supply Mean Well HLG-320H-12B IP67 230V to 12V 22A 264W DIM

Mean Well constant voltage LED transformer for use with LED modules and strips that require 12VDC voltage. The components can be connected in parallel so the total power of the chain is max 22000mA or 264 W. Compact size, dimensions(mm): 252*90*43.8mm .

Features:
  • 90~305VAC input, built-in active PFC function
  • 96% high efficiency (HLG-600H)
  • Metal case, IP67 design for indoor or outdoor installations
  • Function options: 3 in 1 dimming (1~10Vdc or 10V PWM signal or resistance)
  • Type "HL" LED drivers for use in Class I, Division 2 hazardous (Classified) location luminaries
  • Suitable for LED street lighting, outdoor LED lighting and general outdoor applications with high IP requirement
  • 7 years warranty
Technical Data
SKU 95194
Weight brut (g) 1880.000000
Brand Mean Well
Manufacturer Product Code HLG-320H-12B
Output Current (Range) max 22000mA
Transformer Output Voltage 12V
Power (W) 264
IP Protection IP67
Dimmable Dimmable
Dimensions 252x90x43.8mm
Dimensions: Length (cm) 25.2
Dimensions: Width (mm) 90
Dimensions: Height (mm) 43.8
Product Family HLG
Availability beyond shown stock: YES
