Constant Voltage Power Supply Mean Well LPF-25D-24 IP67 230V to 24V 1.1A 25W DIM

€29.20
Stock Germany >10 pcs
SKU
95166
  • Buy 5 for €19.76 each and save 32%

Established in 1982, MEAN WELL is considered a pioneer and a leader in standard switching power supplies all over the world.

MEAN WELL is ranked the 6th in global power supply (DC output) makers according to a report by Micro Technology Consultant released in March 2016. For the product coverage of industrial power supplies and the sales volume of LED drivers, we have the confidence to say that MEAN WELL is ranked the No.1 standard power supply manufacturer in the world.

Constant Voltage Power Supply Mean Well LPF-25D-24 IP67 230V to 24V 1.1A 25W DIM

Mean Well constant voltage LED transformer for use with LED modules and strips that require 24VDC voltage. The components can be connected in parallel so the total power of the chain is max 1100mA or 25 W. Compact size, dimensions(mm): 148*40*32mm .

Features:
  • Built-in 3 in 1 dimming function (1~10VDC, PWM signal or resistance)
  • Fully encapsulated with IP67 level
  • Protections: Short circuit/ Overload/ Over voltage/ Over temperature
  • 90~305VAC input, built-in active PFC function (200~400VAC for LPFH-60/60D)
  • Built-in active PFC function
  • Fully isolated plastic case
  • Isolation class II, no F.G.
  • Class 2 power unit
  • Suitable for dry, damp, wet location
  • 5 years warranty
Technical Data
SKU 95166
Weight brut (kg or g) 0.360000
Manufacturer Mean Well
Manufacturer Product Code LPF-25D-24
Output Current (Range) max 1100mA
Transformer Output Voltage 24V
Power (W) 25
IP Protection IP67
Dimmable Dimmable
Dimensions 148x40x32mm
Product Family LPF
Availability beyond shown stock: YES
