iFlex-RGBW-1080 LED Strip Set RGB-White CRI80 3000K 1180lm 5V 60 individually controllable LEDs/m 5m reel
- 300 RGBW LEDs per 5 m reel (60 LEDs per meter), each individually controllable
- Red, green, blue and warm white 3000K (CRI80) in every LED
- Up to 140 lm red, 430 lm green, 90 lm blue and 440 lm white per reel
- 5 V DC operation, dimmable
- 5 W per color, 20 W with all colors on
- Controller and IR remote control included
- Wide selection of pre-installed light effects, music mode and individual color selection
- Made in Germany, 5-year warranty
iFlex-RGBW-1080 LED Strip Set: Ready-to-Use Addressable RGBW Lighting
The iFlex-RGBW-1080 LED Strip Set contains everything you need to create dynamic, individually controllable lighting effects in living spaces, at events, in shop windows or creative projects. Its heart is a 5 m flexible strip with 300 RGBW LEDs (60 per meter), each of which can be controlled individually: colors, white light and effects can run along the strip, LED by LED.
The included controller and IR remote control give quick access to a wide selection of pre-installed light effects, from gentle color changes to dynamic patterns, a music mode that pulses the light to the rhythm of music, and individual color selection. A power supply with 2 m lead wire and a clip connector for solder-free connection complete the set.
The iFlex is made in Germany with our reel-to-reel process. It can be cut after each LED (every 16.67 mm) to the exact length required, and is installed quickly with its self-adhesive back, without any additional cooling.
Features of the iFlex-RGBW-1080 LED Strip Set
- 300 RGBW LEDs per 5 m reel (60 LEDs per meter), each individually controllable
- Red, green, blue and warm white 3000K (CRI80) in every LED
- Up to 140 lm red, 430 lm green, 90 lm blue and 440 lm white per reel
- 5 V DC operation, dimmable
- 5 W per color, 20 W with all colors on
- Can be cut after each LED (every 16.67 mm)
- Self-adhesive back, no cooling required
- Lifetime of more than 40,000 hours (L80B10)
- Dimensions: 5000 x 10 x 1.72 mm
- Controller and IR remote control included
- Wide selection of pre-installed light effects, music mode and individual color selection
- Power supply with 2 m lead wire and clip connector for solder-free connection
- 5-year warranty
- Made in Germany
Applications of the iFlex-RGBW-1080 LED Strip Set
The iFlex-RGBW-1080 LED Strip Set is designed for the following main applications:
- Cove lighting: In ceiling or wall coves, the strip provides warm white ambient light for everyday use, and colors or running effects for special moments. Learn how to plan it in our cove lighting guide.
- Multi-color lighting with 4 channels: Thanks to the separate white chip, colors and white can be mixed freely, and because each LED is addressable, effects such as color runs, gradients and chasers are possible, ideal for bars, event spaces, shop windows, furniture and exhibition stands. Discover our 4-channel LED strips and modules (RGB-W, multi-color).
- White light: The dedicated warm white chip provides real, pleasant white light with CRI80 instead of a mixed RGB white. The 3000K color temperature gives a soothing warm white light for a relaxing atmosphere. Find out which color temperature suits your project in our guide Choosing the right color temperature for LED lighting.
Technical Data of the iFlex-RGBW-1080 LED Strip Set
- Article number (SKU): 40664
- Equivalent model: iFlex300 ECO
- Light colors: Red, green, blue and warm white 3000K
- Dominant wavelength: Red 615-625 nm, green 525-535 nm, blue 465-470 nm
- Color rendering index (white): CRI80, photometric code 830/339
- Luminous flux (max.): Red 140 lm, green 430 lm, blue 90 lm, white 440 lm per reel (28 / 86 / 18 / 88 lm per meter)
- Beam angle: 120°
- Lifetime: >40,000 h (L80B10C1)
- Operating voltage: 5 V DC, dimmable
- Power: 5 W per color, 20 W with all colors on (5 m reel)
- Number of LEDs: 300 per reel, 60 per meter, individually controllable
- Dimensions: 5000 x 10 x 1.72 mm (L x W x H)
- Cutting interval: after each LED (16.67 mm)
- Operating temperature at Tc: -40°C to +85°C
- Ambient temperature: -40°C to +50°C
- Storage temperature: -40°C to +100°C
- Certifications: CE, RoHS, REACH
- Photobiological safety (EN 62471): Risk group RG0
- Contents of delivery: 1x iFlex-RGBW-1080 LED strip (5 m), 1x clip connector, 1x controller, 1x IR remote control (batteries included), 1x power supply with 2 m lead wire
Installation and Operation
- Cutting: the strip can be cut with scissors after each LED, at the marked cutting points.
- Mounting: clean and degrease the surface, then fix the strip with its self-adhesive back. For a uniform look, we recommend mounting it in one of our aluminum profiles with a diffuser cover.
- Connection: connect the strip to the included controller with the clip connector, without soldering, and plug in the included power supply.
- Operation: choose colors, effects and music mode with the IR remote control.
- Handling: avoid sharp bending and mechanical stress on the components, and keep the strip away from aggressive chemicals.
Who We Are: Ledrise, Professional LED Strips Made in Germany
Ledrise is the international online shop for high-performance LED strips and modules that we develop and manufacture in our own production facility in Germany and ship directly from there. With more than 20 years of experience in LED technology, our team of more than 70 people in Germany, Hong Kong and Romania has gained extensive application knowledge across many sectors, and thousands of business customers and consumers on five continents rely on us as their LED technology partner.
We use only LEDs from market leaders such as Nichia, Seoul Semiconductor, Cree, Samsung and ams OSRAM. Beyond standard products, we design and prototype custom LED modules, select and integrate optics, housings and drivers, and test and validate every solution in our in-house measuring and testing laboratory, supporting you from the first lighting concept to serial production.
Our Quality Promise
- Certified quality: our quality management is certified to DIN EN ISO 9001 and covers every step, from product development to customer service. Our manufacturing center in Germany is also certified to ISO 14001 for environmental management and ISO 45001 for occupational health and safety.
- Reel-to-reel manufacturing, unique in Europe: our fully automated reel-to-reel flex line uses plasma direct metallization to produce robust, flexible circuit boards in continuous lengths of up to 100 meters, with fewer interconnections and less material waste.
- Precision at every step: automated solder paste printing with inline inspection, high-speed ASM SIPLACE component placement, controlled reflow soldering, and automatic optical inspection that detects missing, offset or misaligned components.
- Full traceability: production batches are marked and tracked with laser-engraved barcodes.
- Honest data: the performance values in our datasheets match those in real-world applications.
- Long-term security: a 5-year warranty on this LED strip (see our warranty terms) and professional support for your lighting projects.
Learn more about Ledrise and our reel-to-reel flexible LED strip manufacturing in Germany.
| SKU | 40664 |
|---|---|
| Weight brut (g) | 80.000000 |
| Color | RGBW |
| Color Temperature | 3000K |
| Color Rendering Index | 80 |
| Luminous Flux per meter | 88 |
| Luminous Flux Typ (lm) | 1100 |
| Power (W) | 5 |
| Dimmable | Tunable White, Dimmable, Adjustable color |
| Viewing Angle | 120° |
| Warranty (months) | 60 |
| Product lifetime (h) | 40000 |
| Forward Current Max | 1000mA |
| Product Family | LumiFlex1080 |
| Strip Type | Flexible |
| LEDs per meter | 60 |
| LEDs number per sales unit | 300 |
| Dimensions | 5000x10x1.72 |
| Dimensions: Length (cm) | 500 |
| Dimensions: Width (mm) | 10 |
| Dimensions: Height (mm) | 1.72 |
| Can be cut at (mm) | 16.67 |
| Brand | Lumistrips |
| Manufacturer Part Number | 40595 |
| Forward Voltage Typ (V) | 5 |
