Nichia LED NCSU434A UVC 17mW 280nm 0.5W

Nichia is a leading manufacturer of LED products and a pioneer in the industry
The NCSU434A UV-C LED offers 17.5mW of radiant power at 280nm for only 0.5W of energy consumption, making it cost-effective
The combination of UVA and UV-C LEDs can significantly increase disinfection capabilities
Nichia's LED products are known for their durability, brightness, and homogeneity
Nichia's fine selection of products offers greater added value for professional processing
The NCSU434A comes in a compact 3.5x3.5x1.72mm package with a 120-degree viewing angle
Nichia's innovative research department continuously sets efficiency records, making it a trusted brand in the industry.

€30.65

Stock Germany >10 pcs

SKU

37377

Lumistrips is brand of high performance LED light solutions made in Germany. As part of the early success of LEDs we have extensive application knowledge from a wide range of sectors. Since 2010, we have developed and produced high quality LED strips & modules in a state-of-the-art production facility in Germany. Our LED strips and modules, internationally sold under the LUMISTRIPS brand, use original packaged LEDs from NICHIA, SEOUL SEMICONDUCTOR or SAMSUNG combined with the best PCB and circuit materials.

Our products have been used successfully in a wide range of applications by customers in Europe, North & South America, Asia, Australia.

Nichia is a world-renowned manufacturer of LED products and has been the driving force behind the development of blue and white light-emitting diodes. With an innovative research department dedicated to achieving maximum efficiency, Nichia is a pioneer in the LED industry and continuously sets new records.

The NCSU434A is a new addition to Nichia's line of UV-C LEDs, offering 17.5mW of radiant power for only 0.5W of energy consumption, making it a cost-effective option. It has a typical voltage of 5.3V and current of 100mA, a 120-degree viewing angle and comes in a compact 3.5x3.5x1.72mm package.

Nichia's LED products are known for their durability, brightness, and homogeneity, making them ideal for various applications. The fine selection of products offered by Nichia allows for greater added value for professional processing.

A combination of UVC and UVA LEDs can substantially increase the disinfection capability, as detailed in this article on our blog.

Features

High performance UV-C NCSU434A SMD LED with 280nm and 17.5mW typical radiant power
Typical voltage 5.3V, current 100mA
Typical power consumption: 0.5W
120 deg viewing angle
Dimensions (LxWxH): 3.5x3.5x1.72mm

Application areas

Disinfection
Sterilization

Warning Actinic UV danger for eyes and skin

Ultra violet radiation in the wavelength range of 200-400nm may cause inflammation of the cornea as well as a UV erythema (sunburn) of the skin. The biological effectiveness of the UV radiation varies in the stated wavelength range and is described with the spectral response function (weighting scale) SUV.

See PDF documents for data sheet.

Technical Data
SKU	37377
Weight brut (g)	1.000000
LED Family	Nichia UV (New!)
LED Application	Disinfection
LED Installation Package	Emitter
Color	UVC Ultraviolet
Viewing Angle	120°
Forward Current Typ	350ma
Forward Voltage Typ (V)	5.3
Power (W)	0.5
Wavelength (nm)	280
Manufacturer Product Code	NCSU434A UV-C
Brand	Lumistrips
