Maxline-35-4080 Nichia LED Strip pure white 4000K 1090lm 350mA 35 LEDs 28cm module (3893lm/m 25W/m)
- Unparalleled luminous flux of up to 3900 lm per linear meter at 4000K
- High-performance Nichia 757G series Mid-Power LEDs
- Low power consumption of only 25 watts per meter
- Long lifetime of more than 100,000 hours
- Constant current version at 700mA
- Easy plug & play system for simple installation
- Suitable for use in various applications, including shops, warehouses, factories, and offices
Maxline LED Nichia LED strips are designed to deliver superior performance for various lighting applications. Equipped with an aluminum PCB, these strips maximize the potential of the highest performing Mid-Power LEDs on the market: Nichia 757G series. This allows the luminous flux on a linear meter to reach unparalleled levels, up to 4000 lm while keeping lifetime and light efficacy at very high levels.
The Maxline-35-4080 LED strip is a perfect example of this performance. With only 35 Nichia 757G LEDs, it produces over 3900 lm of white (4000K) light, equivalent to a 400 Watt bulb, while consuming only 25 watts of power. This performance, combined with a lifetime of more than 100,000 hours, makes Maxline an excellent choice for building compact and bright luminaires for use in shops, warehouses, factories, or offices.
Our Nichia Maxline LED modules are the key to building linear lamps or fixtures with superior performance. Integrated into a T8 LED tube or built into a linear luminaire, the Nichia Maxline modules can easily surpass the performance targets for effective and economical sound replacement of fluorescent LED tubes. This outstanding result arises from the use of Nichia 757 Mid-Power LEDs with the highest performance on the market.
The Nichia Maxline modules are available with three LED densities: 14, 35, and 70 LEDs, on an aluminum PCB, in a standard size of 280 x 13 x 4.5 mm. This size standard module is intended for rapid integration into linear LED fixtures or T8 tubes, and on request, longer versions can be made available, with various PCB connectors.
We offer the strips in a constant voltage and constant current version, each with 14, 35, or 70 LEDs. The constant voltage version (24 V) is designed for maximum flexibility in use, while the constant current version is for maximum efficiency. With constant voltage version, many modules can be operated with one power unit in a row. The exact number depends on the version and the power unit.
Features Maxline35:
- Nichia LED module with 35 x Nichia 757G LEDs, 125 LEDs per meter
- Ultra high luminous flux, 1090lm or up to 3900lm per meter
- Pure white 4000K
- Good light qualtiy CRI 80+
- Dimensions (WxHxD): 280 x 13 x 4.5 mm
- All values are at high temperature Tc=85°C
- Recess for screw-mounting
- Replacement for tube lights
- Aluminium PCB for efficient cooling
- 350mA constant current module at 19.6V
- 6.86W per module
- Very bright and efficient
- Simple plug & play system
- 5 years warranty
- Made in Germany
Applications for Maxline LED Nichia Strips:
- Production of compact and very bright luminaires
- Commercial lighting for the presentation of products
- High flux, long-lasting lighting fixtures for shops, offices, TV studios, medical clinics
| SKU | 53326 |
|---|---|
| Weight brut (g) | 1.000000 |
| Color | Neutral White |
| Color Temperature | 4000K |
| Luminous Flux per meter | 3893 |
| Bright like (W) | 325 |
| Luminous Flux Typ (lm) | 1090 |
| Efficacy (lm per W) | 156 |
| Energy Class 2022 | D |
| Power (W) | 25 |
| Viewing Angle | 120° |
| Warranty (months) | 60 |
| Lifetime for residential, 3h daily (yrs) | 92 |
| Product lifetime (h) | 100000 |
| Lifetime for commercial, 12h daily (yrs) | 23 |
| Forward Current Max | 350mA |
| Manufacturer Product Code | 53326 |
| Product Family | Maxline4080 |
| Strip Type | Rigid |
| LEDs per meter | 125 |
| LEDs number per sales unit | 35 |
| Dimensions | 280x16.5x4 |
| Dimensions: Length (cm) | 28 |
| Dimensions: Width (mm) | 16.5 |
| Dimensions: Height (mm) | 4.5 |
| Brand | Lumistrips |
| Manufacturer Part Number | 4260127454117 |
| Forward Voltage Typ (V) | 19.6 |
| Availability beyond shown stock: | NO |
