Lumistrips is brand of high performance LED light solutions made in Germany. As part of the early success of LEDs we have extensive application knowledge from a wide range of sectors. Since 2010, we have developed and produced high quality LED strips & modules in a state-of-the-art production facility in Germany. Our LED strips and modules, internationally sold under the LUMISTRIPS brand, use original packaged LEDs from NICHIA, SEOUL SEMICONDUCTOR or SAMSUNG combined with the best PCB and circuit materials.
Our products have been used successfully in a wide range of applications by customers in Europe, North & South America, Asia, Australia.
The MatrixMini modules are an innovative solution for creating luminaires with large, light surfaces that need uniform, economical, and durable backlighting. Each MatrixMini module measures 3x3 cm and has an easy-to-use Plug & Play interconnect system, making it ideal for building a wide variety of light shapes for different applications. The square of 25 MatrixMini modules is an excellent option for creating square light fixtures.
What's great about MatrixMini is that it provides ample freedom to be creative with lighting design. Our fully pre-assembled MatrixMini-4 LED modules can be easily separated into smaller modules up to 3x3 cm. This modularity feature allows you to customize lighting designs as per your preferences, whether it's MatrixMini-4-4080 (4 modules in a square of 6x6cm), MatrixMini-9-4080 (9 modules in a line of 27x3cm), MatrixMini-25-4080 (25 modules in a square of 15x15cm), or MatrixMini-126-4080 (126 modules in a rectangle of 42x27cm).
With MatrixMini, easy installation is just one of the strengths of our modules. Our high-performance Nichia 757 LEDs deliver up to 80,000 lm / square meter with minimal power consumption and a lifetime of over 100,000 hours. Our innovative PCB design offers LED efficiency of a minimum of 143 lm/Watt, and the Matrix hardly gets warm, eliminating the need for cooling.
The Matrix is built to deliver exceptional flexibility. It can be delivered in one piece with a size of up to 19 x 14 segments (4 LEDs per segment) and operates like one large PCB. It can be separated by hand without tools, and each segment works independently. The connectors on all four sides of the square segment make it easy to build long strings, complex shapes, or large surfaces. Our direct connectors allow the individual Matrix segments to be easily connected with each other, eliminating the need for soldering.
MatrixMini can be used as a technical module for promotional signs, illuminated letters, ambiance lighting, or installed directly to the ceiling or wall without any provisions (24 V) as a technical luminary. It is perfect for projects requiring intense light, with LEDs installed in shapes inside luminaires, directly visible or behind a translucent material such as plexiglass, stone, marble, or barisol. Ledrise LED Matrix concept allows an unlimited variety with one single product.
Our Nichia LED Matrix comes with a warranty of 5 years, and in some cases, it can be extended up to 7 years. The investment is secured over time, with minimal maintenance costs and reduced power consumption, making MatrixMini a cost-effective and sustainable lighting solution.
The freedom of creativity is enhanced by the fact that the MatrixMini 4 LED modules can be ordered in fully pre-assembled forms that can also be separated into smaller modules up to 3x3 cm:
MatrixMini is suitable for construction of light forms, backlight behind translucent surfaces of barisol, plexiglass, stone, etc., illuminated showcases, construction of lighting fixtures or LED panels, general lighting with a long lifetime in shops, offices, TV studios, cabinets, clinics, or in the home. Whether you're refitting old luminaries or creating new ones, MatrixMini offers a versatile, flexible, and energy-efficient lighting solution.
Features
Application areas
Technical data:
SKU | 52707 |
---|---|
Weight brut (g) | 1.000000 |
Color | Warm White |
Color Temperature | 2700K |
Color Rendering Index | 85 |
Luminous Flux Typ (lm) | 1700 |
Efficacy (lm per W) | 117 |
Energy Class 2022 | E |
Power (W) | 12 |
Viewing Angle | 120° |
Warranty (months) | 60 |
Lifetime for residential, 3h daily (yrs) | 92 |
Product lifetime (h) | 100000 |
Lifetime for commercial, 12h daily (yrs) | 23 |
Forward Current Max | 500mA |
Manufacturer Product Code | 52707 |
Product Family | MatrixMini4080 |
Strip Type | Rigid |
LEDs number per sales unit | 100 |
Dimensions | 150x150 |
Dimensions: Length (cm) | 15 |
Dimensions: Width (mm) | 15 |
Brand | Lumistrips |
Forward Voltage Typ (V) | 24 |
Availability beyond shown stock: | YES |
